servo press machine Manufacturer in China
Main technical parameters
| 모델 | PJL-C/5KN-100mm/150V | PJL-C/10KN-100mm/100V | PJL-C/20KN-100mm/125V |
| Maximum pressure (T) | 5 | 10 | 15 |
| Effective stroke(mm) | 100( customizable) | 100( customizable) | 100( customizable) |
| Force resolution (%) | 0.005 | 0.005 | 0.005 |
| Displacement resolution (mm) | 0.001 | 0.001 | 0.001 |
| Weight about (KG) | 200 | 260 | 280 |
| Maximum speed(mm/s) | 150 (customizable) | 100 (customizable) | 125 (customizable) |
| Pressing speed (mm/s) | 0.01-35 | 0.01-35 | 0.01-35 |
| Pressure Range(KN) | 25N-5KN | 25N-10KN | 100N-20KN |
| Holding time (s) | 0.1-200 | 0.1-200 | 0.1-200 |
| Positioning accuracy (mm) | ±0.01 | ±0.01 | ±0.01 |
| Pressure Accuracy (%F.S) | 0.5 | 0.5 | 0.5 |
| Closed mold height (mm) | 300 | 300 | 300 |
| Throat depth(mm) | 120 | 120 | 120 |
| L*W*H(mm) | 580×560×1900 | 545×635×2100 | 545×536×2100 |
| For 3T and above, it is recommended to choose a four-column structure | |||
servo press machine Manufacturer in China
Pinjialing is not only committed to providing cutting-edge equipment technology, but also through our professional efforts, fully support customers to achieve a leap in production efficiency, significantly reduce operating costs, and then move toward a greener and more sustainable development path. We know that whether it is a minor equipment upgrade or a slight improvement in service, it can bring significant benefit growth to our customers. Therefore, Pinjialing always adheres to the core value of innovation and continuously optimizes and upgrades products and services to meet the changing needs of customers and jointly create a better future.
If you are interested in our innovative products and excellent services, or have any questions or needs, we sincerely welcome you to contact us at any time. We will enthusiastically provide you with detailed information and answers, and discuss the possibility of cooperation with you in detail. We look forward to working with you to create a brighter future full of endless opportunities.
The FAQ is regularly updated to reflect the latest information and to ensure that you have the most accurate details at your fingertips.
Thank you for choosing us, and we hope you find the answers you need!
- What is Servo Riveting Machine?
Our servo riveting machine is a kind of automated equipment used for the process of riveting. Riveting is a permanent fastening method that joins two or more materials together using a rivet, which is a metal pin with a head at one end. The rivet is inserted into pre-drilled holes in the materials to be joined, and then the other end is deformed or “headed” to secure the materials in place.
- Do you have an inspection procedure for the product?
Yes, We have a strict inspection of product quality and packing.
- What is the use of Servo Riveting Machine?
Guangdong Pinjialing Intelligent Technology Co. Ltd. is a professional servo press, precision coating and related equipment R & D and manufacturing as one of the modern technology-based enterprises. Our servo riveting machine is used to automatically set (press) rivets to join materials together. The riveting machine offers greater consistency, productivity and lower cost compared to manual riveting.
- Why should I buy from your company not from other suppliers?
As a technology company, Pinjialing’s products have its own core technologies and patents. And has certain influence and popularity in the peer field. We have our own software engineering development department, expert engineering design department, precise production process, strict QC management and high-quality after-sales service.
- How is a servo press machine different from a mechanical press machine?
A servo press machine differs from a mechanical press machine in that it employs a servo motor that provides precise control over the ram’s position and speed, while a mechanical press machine uses a flywheel and clutch to control the ram.
- Which payment terms you can accept?
We can accept flexible payment methods including Bank Transfer, LC, DP, Western Union, Paypal or combined terms as negotiated.
- Is there any warranty after purchasing the servo press?
We have more than 13 years of professional manufacturing experience. We provide 2 years warranty for our servo presses. Technical support is provided free of charge forever.
- What is a servo press machine?
A servo press machine is a type of press machine that uses a servo motor to drive the ram. It provides precise control over the stroke and speed of the ram, allowing for accurate and repeatable forming processes.
- Is it safe to use?
Yes, the Electric Butter Machine is safe when used according to the manufacturer’s instructions. Always follow the safety guidelines and precautions outlined in the instruction manual.
- What are the advantages of using a servo press machine?
The advantages of using a servo press machine include reduced production costs, increased productivity, improved product quality, and better energy efficiency.
